LockedPaper Honeycomb Paper Wrap System HA, un sistema de rendimiento de mayor volumen expande el papel kraft troquelado en una estructura de panal 3D automáticamente. El diseño especial del depósito de polvo para una mejor calidad del aire y la cuchilla opcional para la apariencia del papel dejan una muy buena impresión para los usuarios, una mayor relación de estiramiento para los papeles que ahorran grandes costos para los clientes.
Machine
Jog Speed | 0.5m/s |
Running Speed | 0.1-0.72m/s |
Voltage | 100-240V 50/60Hz |
Net Weight | 22kg |
Machine size (mm) | 706(L)*445(W)*342(H) |
Packing size (mm) | 750(L)*440(W)*380(H) |
Foot pedal
Weight | 0.8kg |
Size(mm) | 200(L)*100(W)*74(H) |
Wire length | 4m |
Features
Proactively collect dust into dust bin
*Less dust to environment, leaves better air quality
*Easier clear and clean the machine, reduce maintenance work
*Less dust left on product for better unboxing experience
Easy to use
*Easy to load paper with slow jog mode
*Driven by foot pedal continuously or fix length each press
*Small footprint for easier integration into pack station
High performance system
*High quality paper: Lockedwave honeycomb paper can be stretched to 4 times of original length before broken
*High stretch ratio: dispenser was set to 2:1 high stretch ratio to better utilize the honeycomb paper
*Optional blade to cut paper end into better appearance
